Assembly

Prerequisites

Definitions

---

1 A byte is 8 bits, a word is 16 bits, a double word (DWORD) is 32 bits, and a quad word (QWORD) is 64 bits.

---

2 Memory is a small card that is installed into the motherboard of a computer. It is faster to access the contents of memory than the contents of a hard drive but slower to access than the contents of a register. A register is a small piece of memory that is built directly into the CPU and is extremely fast. The CPU performs all its operations using registers.

---

3 An immediate is a value that is directly (or immediately) embedded in the operation, as opposed to being fetched from a register or memory. Here are some examples:

mov rax, 3       # Immediate is 3
mov rbx, 0x1234  # Immediate is hex value 0x1234
add rcx, 24      # Immediate is 24
add rbx, rdx     # No immediates here, only registers

---

4 If you have ever been asked, “What’s the sign on the number? Is it a positive or negative sign?” then you have been exposed to signed numbers. A signed number is a number that has the ability to be either positive or negative. There are also unsigned numbers. Unsigned numbers are only positive and do not have the ability to be negative.

Intel Syntax

This reference uses the Intel syntax. That means that instructions are generally as follows:

# instruction destination, source
mov rax, 2   # Move 2 into rax
add rdx, 1   # Add 1 to rdx
mov 1, rdx   # Total nonsense

In the Intel syntax, we have the instruction on the far left (what we want to do), the destination next, and the source last. For example, the mov instruction moves a value from the source to the destination, meaning 2 is moved into register rax. Or in the second example, 1 is added to rdx. But in the third example, we can’t move the value in rdx into 1, as that’s a constant and can’t store anything. You must store the results of your operation in either a register or in memory.

Other

1 You cannot perform memory-to-memory operations in assembly!

---

2 Occasionally I will use rX, mX, and immX to denote a register, memory location, or immediate of X-bits in size. For example, r32 denotes a 32-bit register. At other times, I will just plainly write r, m, or imm to denote a register, dereferenced memory location, or immediate of any size.

General Purpose Registers

There are 16 general-purpose registers, which are in big-endian format. In the table below, registers are listed with the Intel names first, with AMD names in brackets. For example, rax is Intel’s name for this register, but r0 is AMD’s name for the same register. Registers r8 and above are named the same in both AMD and Intel.

64 bits (QWORD)	Lower 32 bits (DWORD)	Lower 16 bits (WORD)	Upper 8 bits (Byte) of WORD	Lower 8 bits (Byte) of WORD
rax (r0)	eax (r0d)	ax (r0w)	ah	al (r0b)
rbx (r3)	ebx (r3d)	bx (r3w)	bh	bl (r3b)
rcx (r1)	ecx (r1d)	cx (r1w)	ch	cl (r1b)
rdx (r2)	edx (r2d)	dx (r2w)	dh	dl (r2b)
rsi (r6)	esi (r6d)	si (r6w)		sil (r6b)
rdi (r7)	edi (r7d)	di (r7w)		dil (r7b)
rbp (r5)	ebp (r5d)	bp (r5w)		bpl (r5b)
rsp (r4)	esp (r4d)	sp (r4w)		spl (r4b)
r8	r8d	r8w		r8b
r9	r9d	r9w		r9b
r10	r10d	r10w		r10b
r11	r11d	r11w		r11b
r12	r12d	r12w		r12b
r13	r13d	r13w		r13b
r14	r14d	r14w		r14b
r15	r15d	r15w		r15b

Basic Instructions

nop

---

Expanded Name

No Operation.

Description

This operation does nothing and takes no arguments. It’s mainly used to pad or align bytes or used as a delay.

Example:

nop

mov

---

Expanded Name

Move.

Description

This instruction moves (it actually copies) a value from one location to another. It may move (it is restricted to moving)

• a value from one register to another register
• a value from memory to a register
• a value from a register to memory
• an immediate to memory
• an immediate to a register

The mov instruction has the form

mov dst, src

Where we move/copy the value from the source (src) to the destination (dst) register or memory location.

Examples

mov rax, 0x14
mov rsp, rax
mov rax, [rsp]
mov rax, [rbx+8]
mov [rax], 6
mov [rax], [rbx]    # Not allowed

1. Moves hex value 0x14 into rax
2. Moves the value in rax into rsp
3. Moves value stored in memory address rsp into rax
4. Moves value stored in memory address rbx+8 into rax. Here, the value in rbx is treated as a memory address, and then that value is offset by 8 bytes. So we get a new memory address, access the value there, and then move that value into rax.
5. Moves the number 6 into memory address rax.
6. This final example attempts to move the value stored in memory address rbx into memory address rax, but it cannot, as memory-to-memory operations are not allowed in assembly.

movsx[d], movzx

---

Expanded Names: Move with sign extend. Move with sign extend, doubleword. Move with zero extend.

Descriptions: The purpose of these instructions is to move a value from a smaller register to a larger register. The same restrictions from mov apply as well.

movsx: “Move with sign extend” keeps the sign of the value when being moved to a larger register. It may either move an 8-bit value to a 16-bit/32-bit register or move a 16-bit register to a 32-bit register.

movsxd: “Move with sign extend, doubleword” is similar to movsx, but extends a 32-bit value into a 64-bit register.

movzx: “Move with zero extend” will discard any sign and will zero out the rest of the larger register after the move operation. Also, there is no movzxd instruction.

Note

You may wish to use movsx and movsxd instead of just mov to keep the sign of a value when moving registers. Just using the mov instruction will cause a negative value to become positive when moved to a larger register (but not when the register is the same size).

Consider the below 8-bit number, its value being -125. The value is negative because the leftmost bit is a one (for signed values).

10000011 # -125 in 8-bit register

When this value is moved to a larger 16-bit register using mov, the leftmost bit is no longer a one, so the value becomes positive! Instead, if we use movsx, ones are filled (sign extended) in the empty space, keeping the value and its sign intact.

0000000010000011 # mov. Becomes +131 :(
1111111110000011 # movsx. Stays -125 :)

movs[b/w/d/q]

---

Expanded Names: Moves byte. Moves word. Moves DWORD. Moves QWORD.

Descriptions: These move instructions are typically meant for string manipulation. It’s used in conjunction with the rep (repeat) instruction to repeatedly copy rcx byte/word/dword/qword from memory address rsi to memory address rdi.

Examples

mov rcx, 8
rep movsb

mov rcx, 2
rep movsw

mov rcx, 3
rep movsd

mov rcx, 26
rep movsq

In all the examples, we move rcx amount of consecutive bytes, words, DWORDS or QWORDs from the memory address pointed to by rsi to the memory address pointed to by rdi.

Just for explicitness, in the first example, we move 8 consecutive bytes (movsb) from the memory address pointed to by rsi to the memory address pointed to by rdi.

add, inc

---

Expanded Names: Add. Increment.

Description

add has the form

add dst, src

It adds the source to the destination. The same restrictions as the mov instruction apply.

The inc instruction will increment a register by one. The add instruction is preferred to this one, as the add instruction will set/reset certain flags (such as the register overflow flag), while this instruction doesn’t.

Examples

add rax, 25
add rbx, rcx
add rdx, [rbx*4]
inc rbx

1. Adds 25 to rax
2. Adds value in rcx to rbx
3. Adds value in memory address rbx*4 to rdx
4. Increments rbx by one

sub, dec

---

Expanded Name

Subtract. Decrement.

The subtract and decrement instructions are similar to the add and inc instructions, but they subtract and decrement instead.

[i]mul

---

Expanded Name

Multiply. Signed (Integer) Multiply.

Description

mul is for unsigned multiplication, and imul is for signed multiplication. This description will focus on the imul instruction, but the same rules apply to mul.

imul (mul) has three forms:

1. imul r/m
2. imul r, r/m
3. imul r, r/m, imm

1 The first form takes just one argument: a register or dereferenced memory address. It takes this argument and implicitly multiplies it with rax. More specifically:

Argument	Implicit	Product
r8/m8	al	ax
r16/m16	ax	dx:ax
r32/m32	eax	edx:eax
r64/m64	rax	rdx:rax

You may notice that, with exception of the 8-bit operation, the result of the multiplication is stored across rdx and rax.

For an 8-bit operation, the maximum value of the multiplication of two 8-bit numbers is 255 × 255 = 65 025. Since the ax register is 16 bits wide, it can hold up to 65 535 values, so the operation can be stored within ax.

For ≥ 16-bit operations, the result of the operation will exceed the size of a single register, so the result must be stored in two registers. For example, the maximum value of the multiplication of two 16-bit numbers would be 65 535 × 65 535 = 4 294 836 225, which is less than the maximum range of a 32-bit number, which is 4 294 967 295. Thus the result is stored in dx:ax, a 32-bit wide concatenation of dx and ax.

While the above result could hold in rax or even eax, registers weren’t always 64-bits or 32-bits wide, so the result had to be stored in two 16-bit registers. For compatibility reasons, as registers grow larger, we keep the way this instruction works the same way. In a future with 128-bit systems, storing rax*r64/m64 in rdx:rax may seem silly, but we currently work in a 64-bit world, so the result has to be stored in these two registers, since there are no 128-bit registers.

2 The second form multiplies r/m and r and stores the result in r. You may perform

• imul r16, r16/m16
• imul r32, r32/m32
• imul r64, r64/m64

Unlike the first form, the result isn’t stored in two registers, just the destination register. This means there’s a possibility of truncation since the result can exceed the size of the register it is stored in.

3 The third form multiplies r/m and imm together and stores the results in r. You may perform:

• imul r16, r16/m16, imm8
• imul r32, r32/m32, imm8
• imul r64, r64/m64, imm8
• imul r16, r16/m16, imm16
• imul r32, r32/m32, imm32
• imul r64, r64/m64, imm32

The reason as to why immX is always less than or equal to the other registers is that the imm value is “sign extended” up to the register or memory size. For example, in the first bullet point, an imm8 would be sign-extended up to a 16-bit width before being multiplied by the 16-bit register/memory. Also, much like the second form, there is a possibility of the result being truncated.

Examples

Example 1

mul r8b

Let r8b = 0x95
Let rax = 0x890E c6d2 4373 ac62

This multiplication is unsigned. What we’re multiplying is r8b = 0x95 and al = 0x62 (see last byte of rax), which is 0x390a. The result will be ax = 0x390a, meaning rax = 0x890e c6d2 4373 390a. Note that only the last byte of rax changed.

Example 2

imul r8d

Let r8d = 0x95
Let rax = 0x890e c6d2 4373 ac62

This multiplication is signed, and we’re using a 32-bit number! What we’re actually multiplying is r8d = 0x0000 0095 and eax = 0x4373 ac62. The result is

• rdx = 0x0000 0000 0000 0027
• rax = 0x0000 0000 4253 550a

Note how in the first example, only the last WORD changed for rax with everything else remaining the same, but in this example, both entire registers changed. The result is placed across rdx and rax with everything else being zeroed out. The result is edx:eax = 0x0000 0027 4253 550a.

Example 3

imul rax, rdx

Let rax = 0x890e c6d2 4373 ac62
Let rdx = 0x000f e7d2 0373 4544

This example is of the second form, so the result is placed in rax alone. The result is rax = 0xf9ef fa67 ae36 3408

[i]div

---

Expanded Name

Division. Signed (Integer) Division.

Description

div is for unsigned division, and idiv is for signed division. This description will focus on the idiv instruction, but the same rules apply to div. Does not perform floating-point division, only whole numbers!

The idiv instruction is carried out by performing

mov rdx/edx/dx, some_value
mov rax/eax/ax, some_value
idiv r/m

As you can see, the division instructions differ from the multiplication instructions in that they only take one argument. View the table below:

Divisor	Dividend	Quotient	Remainder
r8/m8	ax	al	ah
r16/m16	dx:ax	ax	dx
r32/m32	edx:eax	eax	edx
r64/m64	rdx:rax	rax	rdx

Some definitions

• The divisor is the number doing the dividing.
• The dividend is the number being divided.
• The quotient is the whole number result of the division.
• The remainder is what couldn’t be cleanly divided.

As you can see, with the exception of the 8-bit operation, the dividend is stored across rdx and rax, and the results are stored back into rdx and rax, though rdx generally holds the remainder and rax generally holds the quotient.

Note

If you only wish to divide by rax or rdx, you should zero out the other register. Otherwise you will have an unexpected result.

Examples

Example 1

xor rdx, rdx  # Set rdx to zero
mov rax, 0x8
mov rcx, 0x2
div rcx       # Divide rdx:rax by rcx

We first set rdx to zero to simplify this problem, so we’re essentially just dividing rax by rcx. In this case the result is rax = 0x4.

Example 2

mov ax, 0xce
mov cl, 0x5
idiv cl

Here we’re performing an 8-bit division on ax. Here, 0xce (206) is divided by 0x5 (5), which results in the quotient al = 0x29 (41) and remainder ah = 0x1 (1). The result is rax = 0x129. In this case, we don’t need to zero out rdx.

Example 3 ⚠️

mov rdx, 0xffffffffffffffff
mov rax, 0xffffffffffffffff
mov rbx, 0x3
idiv rbx

This will cause a problem. Since the division occurring is by the concatenation of rdx:rax, that means this “register” is 128 bits wide. After dividing by 3, the quotient is far too large to fit into rax and will crash the program. Be aware of this possible issue, as this can occur with values being stored in edx:eax, dx:ax, and ax as well. It is best to ensure that your dividend can fit in a single register if possible (while zeroing out the other).

cmp

---

Expanded Name

Compare.

Description

This instruction compares two values. It is almost always paired with a jump instruction. When a comparison is made, a flag will be set depending on the result. See the jump section for more details on flags.

Compares, combined with jump instructions, are used like an if statement (or any conditional).

// example.cpp
int i = 0
if (i == 14) {
    // do something
}

The comparison checks if i == 14, and the jump instruction will go to another piece of assembly that executes the do something part.

Examples

cmp rax, 0x14
cmp ebx, ecx
cmp qword [rsp+4], rax
cmp qword [rax], rbx

All of the above examples will have the two arguments compared, and flags set based on the outcome. For example, if rax is equal to 0x14, then the ZF flag (zero flag) is set.

jmp instructions

---

Expanded Name

Jump Instructions

Description

There are many jump instructions that are used to satisfy various conditions. Which jump instruction is used depends on what you want, whether the data is signed, unsigned, or if you’re just checking a flag.

When reading the tables, the Flags column denotes what flag(s) the instruction checks to make its decision on whether to jump or not.

🚨 You must pay attention to what flags a jump instruction sets. It’s the only thing that matters when it comes to how the instruction behaves. 🚨

List of Flags

Flag	Full Name	Description
AF	Auxiliary Carry Flag	Used in Binary-Coded Decimal (BCD) math
CF	Carry Flag	If an operation generates a carry or borrow, this flag is set
OF	Overflow Flag	If the result overflows the register, this flag is set
PF	Parity Flag	If the result has an even number of bits set, flag is set (1). If the result has an odd number of bits, flag is unset (0).
SF	Sign Flag	If the result is signed (negative number), this flag is set
ZF	Zero Flag	If the result is zero, this flag is set

The Jump Instruction

Flag	Description
jmp	Unconditionally jump to a label, address, or forward/backward a number of bytes

Signed Jump Instructions

Instruction	Description	Flags
je	Jump if equal to zero	ZF
jg	Jump if greater than zero	OF, SF, ZF
jge	Jump if greater than or equal	OF, SF
jle	Jump if not less than or equal to zero	OF, SF, ZF
jne	Jump if not equal to zero	ZF
jng	Jump if not greater than zero	OF, SF, ZF
jnge	Jump if not greater than or equal	OF, SF
jnle	Jump if not less than or equal to zero	OF, SF, ZF
jnz	Jump if not zero	ZF
jz	Jump if zero	ZF

Unsigned Jump Instructions

Instruction	Description	Flags
ja	Jump if above zero	CF, ZF
jae	Jump if above or equal	CF
jb	Jump if below	CF
jbe	Jump if below or equal	AF, CF
je	Jump if equal to zero	ZF
jna	Jump if not above	AF, CF
jnae	Jump if not above or equal	CF
jnb	Jump if not below	CF
jnbe	Jump if not below zero	CF, ZF
jne	Jump if not equal to zero	ZF
jnz	Jump if not zero	ZF
jz	Jump if zero	ZF

Flag Check Jump Instructions

Instruction	Description	Flags
jc	Jump if carry occurs	CF
jnc	Jump if no carry occurs	CF
jno	Jump if no overflow occurs	OF
jnp	Jump if no parity (same as jpo)	PF
jns	Jump if no sign (positive number)	SF
jo	Jump if overflow occurs	OF
jp	Jump if parity (same as jpe)	PF
jpe	Jump if parity is even (even number of bits set)	PF
jpo	Jump if parity is odd (odd number of bits set)	PF
js	Jump if sign (negative number)	SF
jxcz	Jump if ECX/CX register is zero

Examples

Example 1

mov r9, 14
cmp r9, 14
jne some_label

Simply, r9 and 14 are equivalent, so jne doesn’t jump (because they’re equal).

More complicatedly, we are checking if r9 equals 14, which it does. This is done by subtracting 14 from r9 and checking if the ZF flag is set. If that flag is set, then two values must be the same! Since jne jumps if the two values are not equal, no jump occurs.

Example 2

mov r9, 14
cmp r9, 14
jz some_label

This example isn’t much different from Example 1, except we have swapped jne for the jz (jump if zero) instruction.

Now, one could be forgiven for thinking that since r9 equals 14, and 14 isn’t zero, then no jump occurs. This is wrong.

The cmp instruction performs its comparison by subtracting 14 from r9, and given that they’re the same value, it equals zero. The cmp instruction then sets the ZF flag. Our jump instruction, jz, then comes along and checks for the ZF flag (the only flag it checks), and seeing that it is set, jumps.

Now, you would probably be better off using the je instruction as it reads better than jz, but both do the same thing. What you choose should be based on what you need to do and readability.

Example 3

mov rbx, 11
cmp rbx, 54
jge some_label

Simply put, 11 isn’t greater than 54, so jge doesn’t jump.

But more complicatedly, the cmp instruction subtracts the two operands, this time subtracting 54 from r9 and getting a negative result (the actual value doesn’t matter). The result being negative means that r9 isn’t greater than or equal to 11. Due to the result being negative, the SF flag is set. Based on that set flag, the jge instruction chooses not to jump.

Example 4

cmp rax, rcx
jmp some_label

Ok, so this one was a bit of a trick example. The cmp instruction is completely irrelevant here, since jmp is unconditional and will jump to some_label no matter what.

shr, sar

---

Expanded Name

Shift Right. Shift Arithmetic Right.

Description

shr and sar have the form

shr r/m, imm8/cl
sar r/m, imm8/cl

shr and sar will move the bits in a register or memory location right by imm8 amount of bits or by the value in register cl.

The difference between shr and sar is that sar will sign extend the shift, while shr will only shift in zeroes from the left.

An important application of shr and sar is that they can quickly divide a register or memory location by 2 or a multiple of 2. And doing so is much faster than using div or idiv, with the downside being that no remainder will be calculated.

Examples

Example 1

shr al, 3 # al = 0b11110001

Let al = 0b11110001

I’ve chosen to have al hold a binary value. But hex, decimal, or any other number system will work.

In this case, the value in al will be shifted 3 bits to the right. Note how zeroes are shifted in from the left and that the 1 that was on the far right of our original number has been dropped (shifted out).

0b11110001 # original
0b00011110 # shifted right 3 bits

You can see that our number has changed. If we were to treat the original number as unsigned, then it would equal decimal 241, and after shifting it would equal decimal 30. That is, 241 divided by 2^3 = 30, without remainders. If this number is signed, then the original number would be -15, but the new number would still be 30, which doesn’t make a lot of sense for a division operation.

Example 2

sar al, 3 # al = 0b11110001.

The above example is the same as in Example 1, but we’re using sar instead of shr. This time our value is sign-extended.

0b11110001 # original. Decimal -15
0b11111110 # shifted right 3 bits with sign extension. Decimal -2.

Since we are definitely treating the number as signed, then we have -15/8 = -2. A bit odd, given that -15/8 is actually -1.875, but this operation isn’t capable of calculating floating points, so it’s been effectively rounded up.

Example 3

shr rbx, 7 # rbx = 0xae54

I just wanted to show an example that isn’t binary. To explain the example, I will convert our value in rbx to binary.

rbx = 0xae54 = 0b1010111001010100

0b1010111001010100 # original
0b0000000101011100 # Shifted 7 bits to the right

0b0000000101011100 = 0x15c

So our value in rbx has been changed to 0x15c. This is effectively dividing 0xae54 by 0x80 (0x80 = 2^7 = decimal 128).

shl, sal

---

Expanded Name

Shift Left. Shift Arithmetic Left.

Description

shl and sal have the form:

shl r/m, imm8/cl
sal r/m, imm8/cl

shl and sal will move the bits in a register or memory location left by imm8 amount of bits or by the value in register cl.

Unlike shr and sar, there is no difference between shl and sal. This is because the leftmost bit(s) will be dropped, so whatever the sign bit is doing doesn’t matter.

An important application of shr/sal is that it will quickly multiply a register or memory location by 2 or a multiple of 2. This multiplication is much faster than using mul or imul.

Example:

shl rax, 3 # rax = 0b11110001.

Let’s shift these bits left.

0b11110001 # original
0b011110001000 # shifted left 3 bits

Note that we are using rax, a 64-bit register.

By shifting 3 bits, we are effectively multiplying the value by 8. The original value is decimal 241, and we are effectively multiplying by 8, so the new value is 241×8 = 1928.

lea

---

Expanded Name

Load Effective Address.

Description

The purpose of this instruction is to calculate an address and store it in either a register or memory location. It has the form

lea r/m, [argument]

The argument needs a bit more explaining. You can use the general formula:

argument = [Base register + (Index Register * Scale) + Offset]

The Scale is either 2, 4, or 8 (it can be 1, but there’s no point to multiplying by 1). These values, of course, correspond to bytes, as in 1 byte, 2 bytes (WORD), 4 bytes (DWORD), and 8 bytes (QWORD). Since we work in these ranges, we shouldn’t use a Scale of 3, for example.

And it should be noted that you don’t have to use all of the parameters of the argument. See the example.

You might have noticed that you can perform math operations here and not use mul/imul, add, and sub. This is actually a useful trick, and for simple math operations, lea can sometimes be faster than the standard math instructions. At the very least, it uses fewer instructions. Note that no flags will be set by lea unlike the standard math instructions, so something like overflow can’t be detected.

Example:

lea rax, [rcx]
lea rsi, [rbx+5]
lea rdi, [rbx + rsi * 4 + 3]

This example showcases what you could possibly do with lea. Typically [] means “get the value in that memory address,” but with lea that doesn’t happen. Instead, a memory address is calculated, with that address being stored in the destination register.

Again, you don’t necessarily have to use the result as a memory address; you may also use it as just a math result.

push

---

Description

This instruction moves (“pushes”) a value onto the top of the stack. It also automatically decrements the stack pointer, rsp. It decrements because the stack grows downwards, from higher memory addresses to lower memory addresses.

We may push registers of size r16/32/64, immediates of size imm8/16/32 or values from memory of size m16/32/64. The amount rsp is decremented by depends on the size of the value being pushed onto the stack: 2 bytes from 16-bit values, 4 bytes from 32-bit values, and 8 bytes for 64-bit values.

Despite imm8 as an option, technically byte values cannot be pushed onto the stack, hence rsp only being able to decrement by 2, 4, or 8 bytes. Instead, the imm8 value is sign-extended to 64 bits, then pushed onto the stack.

Examples

push rax
push 0x05
push [rbx+4]

These are examples of simple values being pushed onto the stack: the value inside rax, the immediate 0x05 and the value inside memory address rbx+4.

pop

---

Description

The pop instruction is the opposite of the push instruction. It removes the value off the top of the stack and places that value into a register. It increments the stack pointer, rsp, by the size of the value being popped: 2 bytes for 16-bit values, 4 bytes for 32-bit values, and 8 bytes for 64-bit values.

Example:

pop rax

This will remove the top value off the top of the stack and place it into rax.

call

---

Description

A call instruction allows us to jump to another area in memory, execute a function, and then return to where it last left off. This is sort of like bookmarking a page, going to another chapter and reading something, then returning to your bookmark.

More specifically, the call instruction pushes the next instruction onto the stack (bookmark), sets the rip (instruction pointer) to the memory address where the function is located, and then the CPU will automatically go to where rip points and execute the function there. When the function finishes executing, the “bookmark” will be popped off the stack into rip and the CPU will continue executing from where it left off.

There are different types of calls, but to understand them we need some definitions. This is mostly for knowledge purposes and not particularly important.

1 Far Call

This section is mostly for historical purposes. Far calls are rarely used in modern 64-bit systems (except for certain circumstances), but in older 8-, 16-, and even 32-bit systems, they can be seen more often. The reason for this is that 8-bit systems can “see” up to 256 bytes, 16-bit systems up to ~64 kB, and 32-bit systems up to ~4 GB. But quite often, these systems were allowed to have more memory than that. For example, an 8-bit system could have 64 kB of memory, or a 32-bit system 8 GB of memory. How can these systems use memory that exceeds what they can naturally “see”? Well, just use memory in chunks they can handle.

For example, a 32-bit system can only see ~4 GB at a time, so to use 8GB of memory, just split the 8 GB into two 4 GB chunks. This is essentially the concept of the far call. If some function needed to be called in a different chunk than the current one, a far call would be used to access the “remote” chunk.

Now why does this no longer matter to modern systems? Well, 64-bit systems can see 16 exabytes (quintillions of bytes), while a gaming PC might see 64GB of memory, so there’s no need for a far call.

2 Near Call

Unlike a far call, a near call stays within the same memory chunk and is how modern systems operate. This is referred to as the flat memory model ⤴ and simplifies how memory access works.

3 Relative Address

When one needs to access memory, there are multiple ways to do so, with one being relative addressing. This essentially states, “Go to this address relative to where I am.” Using a book analogy, if we’re at page 240, then relative addressing could state, “Go 30 pages forward” to put us at page 270. For example, jmp +20, jmp my_label or call my_func.

4 Indirect Address

Indirect addressing is like saying, “The address is stored somewhere else,” that somewhere else typically being a pointer. For example, the address may be stored in the rax register. Usage could be jmp rax, jmp [0x123456], or call rbx.

5 Absolute Address

This final address is easy to understand. We refer to the address directly. For example, we could do jmp 0xdeadbeef or call 0xc0ffee.

Example:

call _my_func_2
call rdx

This is how calls are typically made. In this case, these are examples of a near relative call and a near indirect call.

ret

---

Expanded Name

Return.

Description

Returns are always paired with a call. This is how a function returns from executing and goes back to what it was doing before. Look at an example in C++:

int foo() {
    return 5;
}

In the function, the ret instruction in assembly doesn’t care about what’s being returned by the function; that’s the purview of the operating system’s ABI (see Function Conventions for more details). The return in the example, though, is the same as ret in assembly, telling the function to exit and return to what it was executing before.

Example:

# Written in Gnu Assembler

.intel_syntax noprefix
.global main

.section .text
main:
  mov rdi, 2
  mov rsi, 3
  call add_nums

add_nums:
   add rdi, rsi
   mov rax, rdi
   ret

In this example, I decided to write a simple function in GNU Assembly and call it. Below is the rough translation of what it’s doing in C++.

int add_nums(int a, int b) {
    return a + b;
}

int main() {
    add_nums(2, 3);

    // do other stuff
}

The function arguments are stored in rdi and rsi, with the function return stored in rax (see Function Conventions). The function then returns and then goes on to “do other stuff.”

The Stack

The stack is a memory structure meant to hold temporary values, and values on the stack are accessed using a “Last-In-First-Out” (LIFO) method. Think of it as a stack of plates: you put plates on the top of the stack (called pushing) and also remove plates from the top of the stack (called popping). What you don’t do is remove plates from anywhere in the middle of the stack (I mean, you can do that in real life, just not here).

Now, the stack grows down, that is, from higher memory addresses to lower memory addresses. So the top of the stack is at a lower memory address than the bottom of the stack.

Function Conventions

In this section we’ll look at how functions are called. And we’ll be looking at this C++ example:

int foo(int a, int b, int c, int d, int e, int f, int g, int h) {
    int sum = a+b+c+d;
    int product = e*f*g*h;

    return sum + product;
}

int main() {
    int first = 1;
    int answer = foo(first, 2, 3, 4, 5, 6, 7, 8);

    return 0;
}

This example is pretty simple, though foo has a lot of parameters, but there’s a reason for that. We’ll look at how assembly passes the arguments to a function and how data is stored on the stack.

ABI stands for “Application Binary Interface.” It defines how functions are called, how parameters are passed to functions, where the return value is placed, how the stack is cleaned up, and more. We won’t be covering everything to do with ABIs, but enough to write some assembly.

How Functions Work

When we want to call a function, multiple things occur in assembly:

1. The function arguments are placed into registers in accordance with the ABI.
2. The function is called.
3. If there are variables in the function (that are not placed in registers), a stack frame is created.
4. The function runs, and if there is a return value, it’s placed in the appropriate register.
5. The function returns, the stack frame is removed, and the execution continues from where it left off.

Microsoft ABI

The first four function arguments are placed into the following registers, respectively: rcx, rdx, r8, and r9. Further arguments are pushed (moved in fact) onto the stack from right to left.

In the example, rcx = a, rdx = b, r8 = c, r9 = d. Then h is moved onto the stack, followed by g, f, then e. This way the arguments are in order, from top down, since that’s the way we read the stack (LIFO).

The return value, if any, is placed in rax.

System V ABI

The first six arguments are placed into the following registers respectively: rdi, rsi, rdx, rcx, r8, and r9. Further arguments are pushed (moved in fact) onto the stack from right to left.

In the example, rdi = a, rsi = b, rdx = c, rcx = d, r8 = e, and r9 = f. Then h is moved on to the stack, followed by g.

The return value, if any, is placed in rax.

Assembly

.intel_syntax noprefix
.global foo
.global main

.section .text

foo:
    # Create foo stack frame
    push rbp
    mov rbp, rsp

    # sum
    mov eax, edi            # a
    add eax, esi            # a+b
    add eax, edx            # a+b+c
    add eax, ecx            # a+b+c+d

    # product
    mov ebx, r8d            # e
    imul ebx, r9d           # e*f
    mov ecx, dword [rbp+16] # g (stack)
    imul ebx, ecx           # e*f*g
    mov ecx, dword [rbp+20] # h (stack)
    imul ebx, ecx           # e*f*g*h

    # return
    add eax, ebx
    pop rbp
    ret

main:
    # Create main stack frame
    push rbp
    mov rbp, rsp

    # int first = 1
    mov dword [rbp-4], 1

    # foo's arguments
    mov edi, dword [rbp-4]  # a
    mov esi, 2              # b
    mov edx, 3              # c
    mov ecx, 4              # d
    mov r8d, 5              # e
    mov r9d, 6              # f
    sub rsp, 16             # Allocate space on stack
    mov dword [rsp], 7      # g (stack)
    mov dword [rsp+4], 8    # h (stack)

    # foo
    call foo

    # Other
    add rsp, 16             # Clean stack
    mov dword [rbp-8], eax  # int answer = foo()

    # Return
    mov eax, 0              # return 0
    pop rbp
    ret
